MIL-PRF-24699A (SH)
TABLE XV. Conformance inspection.
Inspections
Requirement
Test
paragraph
paragraph
Group A
Dimensions and quantities
Width of rolls (type I)
3.3.1
4.4.1
Quantity of pieces per roll (type I)
3.3.2
4.3.2.1
Size of panels (type II)
Surface density and weight
3.3.3
4.4.2
Surface density
3.4.1
4.4.2.1
Weight of rolls (type I)
3.4.2
4.4.2.2
Workmanship
3.12
4.3.2.1
Group B
Breaking force
3.5
4.4.3
Tearing strength (type I)
3.6
4.4.4
Rivet and grommet load bearing strength
3.6.1
4.4.4.1
Flexural rigidity
3.7
4.4.5
Peel strength (type I)
3.8
4.4.6
4.3.1 Lot. A lot shall consist of all finished material of one size produced in a continuous run (or at the
same time and under the same conditions) and offered for delivery at one time. The sampling unit shall be one roll
or panel.
4.3.2 Sampling.
4.3.2.1 Sampling for visual and dimensional examination. For visual and dimensional examination (group
A of Table XV), a random sample shall be selected from each lot in accordance with ASQC Z1.4 at inspection
level I. Each of the samples taken shall be subjected to surface examination for quantity of pieces per roll and
workmanship (see Table XVI). Any defects detected during the inspection shall be cause for rejection.
Table XVI. Classification of defects.
Examine
Defect
Major
Minor
End item
Length and width not as specified.
X
Cracks, scratches, dents, imbedded particles.
X
Broken edges or corners (type II)
X
Damage or defects affecting function or serviceability.
X
Excessive quantity of pieces per roll.
X
4.3.2.2 Sampling for conformance tests. For quality conformance inspection requiring tests (group B of
Table XV), a random sample shall be selected from each lot in accordance with ASQC Z1.4, level S-2. Any
defects detected during the inspection shall be cause for rejection.
4.3.2.3 Nonconformance. If a sample fails to pass group B inspection, the contractor shall notify the
qualifying activity and the cognizant inspection activity of such failure and take corrective action on the materials
or processes, or both, as warranted, and on all units of product which can be corrected and which were
manufactured under essentially the same materials and processes, and which are considered subject to the same
failure. Acceptance and shipment of the product shall be discontinued until corrective action acceptable to the
contracting activity has been taken. After the corrective action has been taken, group B inspection shall be
repeated on additional sample units (all tests and examinations, or the test which the original sample failed at the
option of the qualifying activity). Group A inspections may be reinstituted; however, final acceptance and
160p8" style="font-size:12px">8
