MIL-DTL-24688 Insulation, Thermal And Acoustic Absorptive, Cellular Polyimide FoamThis specification covers thermal and acoustic absorptive cellular polyimide foam insulation for use on bulkheads, overheads, and ventilation ducting. This specification also covers preformed thermal pipe insulation for use on piping operating at temperatures up to 600 degrees F in shipboard applications \(see 6.1\).

Pages 1 - - 4 - 5 - 6 - 7 - 8|||9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22|||


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MIL-DTL-24688A
TABLE VII. Conformance inspection.
Inspection
Requirement
Test
Group A
Dimensions and tolerances
Type I and Type II
Type III
Weights and tolerances
Type I and Type II
Type III
Identification markings
Group B
Adhesive
Type II, all classes and Type III, Classes 2, 4, and 6
Facing alignment
Type II, Classes 1, 3, 4, and 5 and Type III
Type II, Class 2
Paintability
Type II, Classes 1, 3, 4, and 5 and Type III, Classes
2, 4, and 6
Sound absorption
Type I and Type II, Class 2
Thermal conductivity
Type I and Type II
Type III
Upper temperature limit
Type I, Type II, and Type III
Group C
Cutability
Type II
Mass loss by tumbling
Type I and Type III
Corrosiveness
Type I and Type III
Wicking
Type I and Type III
Puncture resistance
Type II, Class 1
Compressibility
Type I, Type II, and Type III, Classes 1 and 2
Type III, Classes 3 and 4
Type III, Classes 5 and 6
